Minimal Digital Media Server implementation. More...

#include <MediaServer.h>

Inheritance diagram for tiny_dlna::MediaServer:

Collaboration diagram for tiny_dlna::MediaServer:

[legend]

Public Types
typedef void(*	PrepareDataCallback) (const char objectID, const char browseFlag, const char filter, int startingIndex, int requestedCount, const char sortCriteria, int &numberReturned, int &totalMatches, int &updateID, void *reference)

typedef bool(*	GetDataCallback) (int index, MediaItem &item, void *reference)

Public Member Functions
	MediaServer ()

	~MediaServer ()

void	end ()

void	setupServices (HttpServer &server, IUDPService &udp)
	to be implemented by subclasses

void	setPrepareDataCallback (PrepareDataCallback cb)
	Sets the PrepareData callback.

void	setGetDataCallback (GetDataCallback cb)
	Sets the GetData callback.

void	setReference (void *ref)
	Sets a user reference pointer, available in callbacks.

HttpServer *	getHttpServer ()
	Provides access to the http server.

Public Member Functions inherited from tiny_dlna::DLNADeviceInfo
	DLNADeviceInfo (bool ok=true)

	~DLNADeviceInfo ()

virtual bool	begin ()
	Override to initialize the device.

void	print (Print &out)
	renderes the device xml

void	setDeviceType (const char *st)

const char *	getDeviceType ()

void	setUDN (const char *id)
	Define the udn uuid.

const char *	getUDN ()
	Provide the udn uuid.

void	setBaseURL (const char *url)
	Defines the base url.

void	setBaseURL (IPAddress ip, int port, const char *path="")
	Defines the base URL.

const char *	getBaseURL ()
	Provides the base url.

Url &	getDeviceURL ()
	This method returns base url/device.xml.

void	setIPAddress (IPAddress address)
	Defines the local IP address.

IPAddress	getIPAddress ()
	Provides the local IP address.

const char *	getIPStr ()
	Provides the local address as string.

void	setNS (const char *ns)

const char *	getNS ()

void	setFriendlyName (const char *name)

const char *	getFriendlyName ()

void	setManufacturer (const char *man)

const char *	getManufacturer ()

void	setManufacturerURL (const char *url)

const char *	getManufacturerURL ()

void	setModelDescription (const char *descr)

const char *	getModelDescription ()

void	setModelName (const char *name)

const char *	getModelName ()

void	setModelNumber (const char *number)

const char *	getModelNumber ()

void	setSerialNumber (const char *sn)

const char *	getSerialNumber ()

void	setUniveralProductCode (const char *upc)

const char *	getUniveralProductCode ()

void	addService (DLNAServiceInfo s)
	Adds a service defintion.

DLNAServiceInfo &	getService (const char *id)
	Finds a service definition by name.

Vector< DLNAServiceInfo > &	getServices ()

void	clear ()

void	clearIcons ()
	Overwrite the default icon.

void	addIcon (Icon icon)

Icon	getIcon (int idx=0)

	operator bool ()

void	updateTimestamp ()
	Update the timestamp.

uint32_t	getTimestamp ()
	Returns the time when this object has been updated.

void	setActive (bool flag)

virtual void	loop ()

Protected Member Functions
void	setupServicesImpl (HttpServer *server)

Protected Member Functions inherited from tiny_dlna::DLNADeviceInfo
virtual void	setupServices (HttpServer &server, IUDPService &udp)
	to be implemented by subclasses

size_t	printRoot ()

size_t	printDevice ()

size_t	printSpecVersion ()

size_t	printServiceList ()

size_t	printService (void *srv)

size_t	printIconList ()

size_t	printIconDlnaInfo (Icon &icon)

Static Protected Member Functions
static const char *	replyTemplate ()

static void	contentDirectoryControlCB (HttpServer server, const char requestPath, HttpRequestHandlerLine *hl)

static void	writeEscapedText (Print &out, const char *s)

static void	streamReplyCallback (Print &out)

static void	buildEscapedDIDL (Print &out, GetDataCallback get_data_cb, int count)

static void	connmgrControlCB (HttpServer server, const char requestPath, HttpRequestHandlerLine *hl)

Protected Attributes
const char *	st = "urn:schemas-upnp-org:device:MediaServer:1"

const char *	usn = "uuid:media-server-0000-0000-0000-000000000001"

PrepareDataCallback	prepare_data_cb = nullptr

GetDataCallback	get_data_cb = nullptr

HttpServer *	p_server = nullptr

void *	reference_ = nullptr

Protected Attributes inherited from tiny_dlna::DLNADeviceInfo
uint64_t	timestamp = 0

bool	is_active = true

XMLPrinter	xml

Url	device_url

IPAddress	localhost

int	version_major = 1

int	version_minor = 0

const char *	base_url = "http://localhost:9876/dlna"

const char *	udn = "uuid:09349455-2941-4cf7-9847-0dd5ab210e97"

const char *	ns = "xmlns=\"urn:schemas-upnp-org:device-1-0\""

const char *	device_type = nullptr

const char *	friendly_name = nullptr

const char *	manufacturer = nullptr

const char *	manufacturer_url = nullptr

const char *	model_description = nullptr

const char *	model_name = nullptr

const char *	model_url = nullptr

const char *	model_number = nullptr

const char *	serial_number = nullptr

const char *	universal_product_code = nullptr

Icon	icon

Vector< DLNAServiceInfo >	services

Vector< Icon >	icons

Str	url_str

Static Protected Attributes
static GetDataCallback	g_stream_get_data_cb = nullptr

static int	g_stream_numberReturned = 0

static int	g_stream_totalMatches = 0

static int	g_stream_updateID = 0

static void *	g_stream_reference = nullptr

Detailed Description

Minimal Digital Media Server implementation.

This class implements a lightweight DLNA MediaServer device with a ContentDirectory service (Browse) and a ConnectionManager service.

The API is designed for embedding custom content lists and streaming logic. Instead of a single browse callback, the API now uses two callbacks:

PrepareDataCallback: Called to determine the number of items, total matches, and update ID for a Browse request.
GetDataCallback: Called for each item to retrieve its metadata (MediaItem) by index.

A user reference pointer can be set with setReference(void*), and is passed to both callbacks for custom context or data.

Example usage:

Implement PrepareDataCallback and GetDataCallback.
Register them with setPrepareDataCallback() and setGetDataCallback().
Optionally set a reference pointer with setReference().

The implementation is intentionally compact and suitable as a starting point for embedded or test DLNA servers.

Member Typedef Documentation

◆ GetDataCallback

typedef bool(* tiny_dlna::MediaServer::GetDataCallback) (int index, MediaItem &item, void *reference)

◆ PrepareDataCallback

typedef void(* tiny_dlna::MediaServer::PrepareDataCallback) (const char *objectID, const char *browseFlag, const char *filter, int startingIndex, int requestedCount, const char *sortCriteria, int &numberReturned, int &totalMatches, int &updateID, void *reference)

Constructor & Destructor Documentation

◆ MediaServer()

tiny_dlna::MediaServer::MediaServer ( )

inline

◆ ~MediaServer()

tiny_dlna::MediaServer::~MediaServer ( )

inline

Member Function Documentation

◆ buildEscapedDIDL()

static void tiny_dlna::MediaServer::buildEscapedDIDL	(	Print &	out,
		GetDataCallback	get_data_cb,
		int	count
	)

inlinestaticprotected

◆ connmgrControlCB()

static void tiny_dlna::MediaServer::connmgrControlCB	(	HttpServer *	server,
		const char *	requestPath,
		HttpRequestHandlerLine *	hl
	)

inlinestaticprotected

◆ contentDirectoryControlCB()

static void tiny_dlna::MediaServer::contentDirectoryControlCB	(	HttpServer *	server,
		const char *	requestPath,
		HttpRequestHandlerLine *	hl
	)

inlinestaticprotected

◆ end()

void tiny_dlna::MediaServer::end ( )

inline

◆ getHttpServer()

HttpServer * tiny_dlna::MediaServer::getHttpServer ( )

inline

Provides access to the http server.

◆ replyTemplate()

static const char * tiny_dlna::MediaServer::replyTemplate ( )

inlinestaticprotected

generic SOAP reply template with placeholders: %1 = ActionResponse, %2 = ServiceName, %3 = inner payload

◆ setGetDataCallback()

void tiny_dlna::MediaServer::setGetDataCallback ( GetDataCallback cb )

inline

Sets the GetData callback.

◆ setPrepareDataCallback()

void tiny_dlna::MediaServer::setPrepareDataCallback ( PrepareDataCallback cb )

inline

Sets the PrepareData callback.

◆ setReference()

void tiny_dlna::MediaServer::setReference ( void * ref )

inline

Sets a user reference pointer, available in callbacks.

◆ setupServices()

void tiny_dlna::MediaServer::setupServices	(	HttpServer &	server,
		IUDPService &	udp
	)

inlinevirtual

to be implemented by subclasses

Reimplemented from tiny_dlna::DLNADeviceInfo.

◆ setupServicesImpl()

void tiny_dlna::MediaServer::setupServicesImpl ( HttpServer * server )

inlineprotected

◆ streamReplyCallback()

static void tiny_dlna::MediaServer::streamReplyCallback ( Print & out )

inlinestaticprotected

◆ writeEscapedText()

static void tiny_dlna::MediaServer::writeEscapedText	(	Print &	out,
		const char *	s
	)

inlinestaticprotected

Member Data Documentation

◆ g_stream_get_data_cb

GetDataCallback tiny_dlna::MediaServer::g_stream_get_data_cb = nullptr

inlinestaticprotected

◆ g_stream_numberReturned

int tiny_dlna::MediaServer::g_stream_numberReturned = 0

inlinestaticprotected

◆ g_stream_reference

void* tiny_dlna::MediaServer::g_stream_reference = nullptr

inlinestaticprotected

◆ g_stream_totalMatches

int tiny_dlna::MediaServer::g_stream_totalMatches = 0

inlinestaticprotected

◆ g_stream_updateID

int tiny_dlna::MediaServer::g_stream_updateID = 0

inlinestaticprotected

◆ get_data_cb

GetDataCallback tiny_dlna::MediaServer::get_data_cb = nullptr

protected

◆ p_server

HttpServer* tiny_dlna::MediaServer::p_server = nullptr

protected

◆ prepare_data_cb

PrepareDataCallback tiny_dlna::MediaServer::prepare_data_cb = nullptr

protected

◆ reference_

void* tiny_dlna::MediaServer::reference_ = nullptr

protected

◆ st

const char* tiny_dlna::MediaServer::st = "urn:schemas-upnp-org:device:MediaServer:1"

protected

◆ usn

const char* tiny_dlna::MediaServer::usn = "uuid:media-server-0000-0000-0000-000000000001"

protected

The documentation for this class was generated from the following file:

src/dlna/devices/MediaServer/MediaServer.h
