#include <MediaRenderer.h>

Inheritance diagram for tiny_dlna::MediaRenderer:

Collaboration diagram for tiny_dlna::MediaRenderer:

[legend]

Public Types
typedef void(*	MediaEventHandler) (MediaEvent event, MediaRenderer &renderer)

Public Member Functions
	MediaRenderer ()
	Default constructor.

void	setMediaEventHandler (MediaEventHandler cb)
	Register a media event handler callback.

bool	setVolume (uint8_t volumePercent)
	Set the renderer volume (0..100 percent)

uint8_t	getVolume ()
	Get current volume (0..100 percent)

bool	setMute (bool mute)
	Enable or disable mute.

bool	isMuted ()
	Query mute state.

bool	isActive ()
	Query whether renderer is active (playing or ready)

void	setActive (bool active)
	Set the active state (used by transport callbacks)

unsigned long	getPosition ()
	Get estimated playback position (ms)

const char *	getMime ()
	Provides the mime from the DIDL or nullptr.

const char *	getCurrentUri ()

const char *	getTransportState ()
	Get textual transport state.

Public Member Functions inherited from tiny_dlna::DLNADeviceInfo
	DLNADeviceInfo (bool ok=true)

	~DLNADeviceInfo ()

virtual bool	begin ()
	Override to initialize the device.

void	print (Print &out)
	renderes the device xml

void	setDeviceType (const char *st)

const char *	getDeviceType ()

void	setUDN (const char *id)
	Define the udn uuid.

const char *	getUDN ()
	Provide the udn uuid.

void	setBaseURL (const char *url)
	Defines the base url.

void	setBaseURL (IPAddress ip, int port, const char *path="")
	Defines the base URL.

const char *	getBaseURL ()
	Provides the base url.

Url &	getDeviceURL ()
	This method returns base url/device.xml.

void	setIPAddress (IPAddress address)
	Defines the local IP address.

IPAddress	getIPAddress ()
	Provides the local IP address.

const char *	getIPStr ()
	Provides the local address as string.

void	setNS (const char *ns)

const char *	getNS ()

void	setFriendlyName (const char *name)

const char *	getFriendlyName ()

void	setManufacturer (const char *man)

const char *	getManufacturer ()

void	setManufacturerURL (const char *url)

const char *	getManufacturerURL ()

void	setModelDescription (const char *descr)

const char *	getModelDescription ()

void	setModelName (const char *name)

const char *	getModelName ()

void	setModelNumber (const char *number)

const char *	getModelNumber ()

void	setSerialNumber (const char *sn)

const char *	getSerialNumber ()

void	setUniveralProductCode (const char *upc)

const char *	getUniveralProductCode ()

void	addService (DLNAServiceInfo s)
	Adds a service defintion.

DLNAServiceInfo &	getService (const char *id)
	Finds a service definition by name.

Vector< DLNAServiceInfo > &	getServices ()

void	clear ()

void	clearIcons ()
	Overwrite the default icon.

void	addIcon (Icon icon)

Icon	getIcon (int idx=0)

	operator bool ()

void	updateTimestamp ()
	Update the timestamp.

uint32_t	getTimestamp ()
	Returns the time when this object has been updated.

void	setActive (bool flag)

virtual void	loop ()

Protected Member Functions
void	setupServices (HttpServer &server, IUDPService &udp)
	Setup the HTTP and UDP services.

bool	play (const char *urlStr)
	Start playback of a network resource (returns true on success)

void	setMime (const char *mime)
	Set MIME explicitly (used when DIDL-Lite metadata provides protocolInfo)

void	playbackCompleted ()
	Notify the renderer that playback completed.

void	setMimeFromDIDL (const char *didl)

void	setupServicesImpl (HttpServer *server)

Protected Member Functions inherited from tiny_dlna::DLNADeviceInfo
virtual void	setupServices (HttpServer &server, IUDPService &udp)
	to be implemented by subclasses

size_t	printRoot ()

size_t	printDevice ()

size_t	printSpecVersion ()

size_t	printServiceList ()

size_t	printService (void *srv)

size_t	printIconList ()

size_t	printIconDlnaInfo (Icon &icon)

Static Protected Member Functions
static const char *	reply ()

static void	transportControlCB (HttpServer server, const char requestPath, HttpRequestHandlerLine *hl)

static void	renderingControlCB (HttpServer server, const char requestPath, HttpRequestHandlerLine *hl)

Protected Attributes
tiny_dlna::Str	current_uri

tiny_dlna::Str	current_mime

MediaEventHandler	event_cb = nullptr

uint8_t	current_volume = 50

bool	is_muted = false

bool	is_active = false

unsigned long	start_time = 0

tiny_dlna::Str	transport_state = "NO_MEDIA_PRESENT"

const char *	st = "urn:schemas-upnp-org:device:MediaRenderer:1"

const char *	usn = "uuid:09349455-2941-4cf7-9847-1dd5ab210e97"

Protected Attributes inherited from tiny_dlna::DLNADeviceInfo
uint64_t	timestamp = 0

bool	is_active = true

XMLPrinter	xml

Url	device_url

IPAddress	localhost

int	version_major = 1

int	version_minor = 0

const char *	base_url = "http://localhost:9876/dlna"

const char *	udn = "uuid:09349455-2941-4cf7-9847-0dd5ab210e97"

const char *	ns = "xmlns=\"urn:schemas-upnp-org:device-1-0\""

const char *	device_type = nullptr

const char *	friendly_name = nullptr

const char *	manufacturer = nullptr

const char *	manufacturer_url = nullptr

const char *	model_description = nullptr

const char *	model_name = nullptr

const char *	model_url = nullptr

const char *	model_number = nullptr

const char *	serial_number = nullptr

const char *	universal_product_code = nullptr

Icon	icon

Vector< DLNAServiceInfo >	services

Vector< Icon >	icons

Str	url_str

Detailed Description

MediaRenderer DLNA Device.

MediaRenderer implements a simple UPnP/DLNA Media Renderer device. It receives stream URIs via UPnP AVTransport actions and delegates actual playback and rendering to the application through an event callback API. This removes any dependency on an internal audio stack: applications handle playback themselves by registering a handler with setMediaEventHandler(). The device still supports rendering controls (volume, mute) and transport controls (play/pause/stop) and provides helper accessors like getCurrentUri() and getMime().

Usage summary:

Register an event handler with setMediaEventHandler() to receive MediaEvent notifications (SET_URI, PLAY, PAUSE, STOP, SET_VOLUME, SET_MUTE).
In the handler query the renderer (getCurrentUri(), getVolume(), isMuted(), getMime()) and implement platform-specific playback.
Use play(url) to programmatically start playback; the handler will also be notified of SET_URI and PLAY when the device receives a SetAVTransportURI SOAP action.

This class is intentionally small and Arduino-friendly: methods return bool for success/failure and avoid heavy dynamic memory allocations in the hot path.

Author: Phil Schatzmann

Member Typedef Documentation

◆ MediaEventHandler

typedef void(* tiny_dlna::MediaRenderer::MediaEventHandler) (MediaEvent event, MediaRenderer &renderer)

Constructor & Destructor Documentation

◆ MediaRenderer()

tiny_dlna::MediaRenderer::MediaRenderer ( )

inline

Default constructor.

Initializes device metadata (friendly name, manufacturer, model) and sets default base URL and identifiers. It does not configure any audio pipeline components; use setOutput() and setDecoder() for that.

Member Function Documentation

◆ getCurrentUri()

const char * tiny_dlna::MediaRenderer::getCurrentUri ( )

inline

◆ getMime()

const char * tiny_dlna::MediaRenderer::getMime ( )

inline

Provides the mime from the DIDL or nullptr.

◆ getPosition()

unsigned long tiny_dlna::MediaRenderer::getPosition ( )

inline

Get estimated playback position (ms)

◆ getTransportState()

const char * tiny_dlna::MediaRenderer::getTransportState ( )

inline

Get textual transport state.

◆ getVolume()

uint8_t tiny_dlna::MediaRenderer::getVolume ( )

inline

Get current volume (0..100 percent)

◆ isActive()

bool tiny_dlna::MediaRenderer::isActive ( )

inline

Query whether renderer is active (playing or ready)

◆ isMuted()

bool tiny_dlna::MediaRenderer::isMuted ( )

inline

Query mute state.

◆ play()

bool tiny_dlna::MediaRenderer::play ( const char * urlStr )

inlineprotected

Start playback of a network resource (returns true on success)

◆ playbackCompleted()

void tiny_dlna::MediaRenderer::playbackCompleted ( )

inlineprotected

Notify the renderer that playback completed.

This helper updates the internal transport state to "STOPPED", marks the renderer inactive, resets the start time, logs the event and notifies the application event handler with MediaEvent::STOP so the application can perform cleanup (release resources, update UI, etc.).

◆ renderingControlCB()

static void tiny_dlna::MediaRenderer::renderingControlCB	(	HttpServer *	server,
		const char *	requestPath,
		HttpRequestHandlerLine *	hl
	)

inlinestaticprotected

◆ reply()

static const char * tiny_dlna::MediaRenderer::reply ( )

inlinestaticprotected

◆ setActive()

void tiny_dlna::MediaRenderer::setActive ( bool active )

inline

Set the active state (used by transport callbacks)

◆ setMediaEventHandler()

void tiny_dlna::MediaRenderer::setMediaEventHandler ( MediaEventHandler cb )

inline

Register a media event handler callback.

◆ setMime()

void tiny_dlna::MediaRenderer::setMime ( const char * mime )

inlineprotected

Set MIME explicitly (used when DIDL-Lite metadata provides protocolInfo)

◆ setMimeFromDIDL()

void tiny_dlna::MediaRenderer::setMimeFromDIDL ( const char * didl )

inlineprotected

Try to parse a DIDL-Lite snippet and extract the protocolInfo MIME from the <res> element. If found, set current_mime.

◆ setMute()

bool tiny_dlna::MediaRenderer::setMute ( bool mute )

inline

Enable or disable mute.

◆ setupServices()

void tiny_dlna::MediaRenderer::setupServices	(	HttpServer &	server,
		IUDPService &	udp
	)

inlineprotectedvirtual

Setup the HTTP and UDP services.

Reimplemented from tiny_dlna::DLNADeviceInfo.

◆ setupServicesImpl()

void tiny_dlna::MediaRenderer::setupServicesImpl ( HttpServer * server )

inlineprotected

◆ setVolume()

bool tiny_dlna::MediaRenderer::setVolume ( uint8_t volumePercent )

inline

Set the renderer volume (0..100 percent)

◆ transportControlCB()

static void tiny_dlna::MediaRenderer::transportControlCB	(	HttpServer *	server,
		const char *	requestPath,
		HttpRequestHandlerLine *	hl
	)

inlinestaticprotected

Member Data Documentation

◆ current_mime

tiny_dlna::Str tiny_dlna::MediaRenderer::current_mime

protected

◆ current_uri

tiny_dlna::Str tiny_dlna::MediaRenderer::current_uri

protected

◆ current_volume

uint8_t tiny_dlna::MediaRenderer::current_volume = 50

protected

◆ event_cb

MediaEventHandler tiny_dlna::MediaRenderer::event_cb = nullptr

protected

◆ is_active

bool tiny_dlna::MediaRenderer::is_active = false

protected

◆ is_muted

bool tiny_dlna::MediaRenderer::is_muted = false

protected

◆ st

const char* tiny_dlna::MediaRenderer::st = "urn:schemas-upnp-org:device:MediaRenderer:1"

protected

◆ start_time

unsigned long tiny_dlna::MediaRenderer::start_time = 0

protected

◆ transport_state

tiny_dlna::Str tiny_dlna::MediaRenderer::transport_state = "NO_MEDIA_PRESENT"

protected

◆ usn

const char* tiny_dlna::MediaRenderer::usn = "uuid:09349455-2941-4cf7-9847-1dd5ab210e97"

protected

The documentation for this class was generated from the following file:

src/dlna/devices/MediaRenderer/MediaRenderer.h
