Helper class to control/query a MediaServer from a control point. More...

#include <ControlPointMediaServer.h>

Collaboration diagram for tiny_dlna::ControlPointMediaServer:

[legend]

Public Types
typedef void(*	ItemCallback) (const MediaItem &item, void *ref)

typedef void(*	NotificationCallback) (void reference, const char sid, const char varName, const char newValue)

Public Member Functions
	ControlPointMediaServer (DLNAControlPointMgr &mgr)
	Construct helper with reference to control point manager.

bool	begin (DLNAHttpRequest &http, IUDPService &udp, uint32_t minWaitMs=3000, uint32_t maxWaitMs=60000)
	Begin discovery and processing (forwards to underlying control point)

int	getDeviceCount ()
	Return number of discovered devices known to the control point.

const ActionReply &	getLastReply () const
	Return the ActionReply from the last synchronous request.

void	setDeviceIndex (int idx)
	Select a device by index (0-based) for subsequent actions.

bool	subscribeNotifications (int timeoutSeconds=60, NotificationCallback cb=nullptr)
	Subscribe to event notifications for the selected server/device.

void	setDeviceTypeFilter (const char *filter)
	Restrict this helper to devices of the given device type.

void	setReference (void *ref)
	Attach an opaque reference pointer passed to callbacks.

bool	browse (int startingIndex, int requestedCount, ItemCallback itemCallback, int &numberReturned, int &totalMatches, int &updateID, const char *browseFlag=nullptr)
	Browse the given object_id and invoke callback for each returned item.

int	getSystemUpdateID ()
	Get current SystemUpdateID for the ContentDirectory.

const char *	getSearchCapabilities ()
	Get the ContentDirectory SearchCapabilities string.

const char *	getSortCapabilities ()
	Get the ContentDirectory SortCapabilities string.

const char *	getProtocolInfo ()
	Query ConnectionManager:GetProtocolInfo.

void	setObjectID (const char *id)
	Set the object id used for browse operations (default: "0")

const char *	getObjectID () const
	Return the current object id used for browse.

Protected Member Functions
DLNAServiceInfo &	selectService (const char *id)
	Select service by id.

const char *	findArgument (ActionReply &r, const char *name)

ActionRequest &	createBrowseAction (DLNAServiceInfo &svc, const char *browseFlag, int startingIndex, int requestedCount)
	Build a Browse ActionRequest.

void	parseNumericFields (ActionReply &reply, int &numberReturned, int &totalMatches, int &updateID)
	Parse numeric result fields from an ActionReply.

void	processResult (const char *resultXml, ItemCallback itemCallback)
	Parse DIDL-Lite Result and invoke callback for each item.

Static Protected Member Functions
static void	processNotification (void reference, const char sid, const char varName, const char newValue)
	Notification callback: just log for now.

Protected Attributes
DLNAControlPointMgr &	mgr

int	device_index = 0

const char *	device_type_filter_default

const char *	device_type_filter = device_type_filter_default

ActionReply	last_reply

StringRegistry	strings

void *	reference = nullptr

const char *	object_id = "0"

Detailed Description

Helper class to control/query a MediaServer from a control point.

Provides convenient wrappers around common ContentDirectory and ConnectionManager actions (Browse, GetSystemUpdateID, GetSearchCapabilities, GetProtocolInfo). Methods are synchronous and return boolean success or populate output parameters.

Member Typedef Documentation

◆ ItemCallback

typedef void(* tiny_dlna::ControlPointMediaServer::ItemCallback) (const MediaItem &item, void *ref)

◆ NotificationCallback

typedef void(* tiny_dlna::ControlPointMediaServer::NotificationCallback) (void *reference, const char *sid, const char *varName, const char *newValue)

Constructor & Destructor Documentation

◆ ControlPointMediaServer()

tiny_dlna::ControlPointMediaServer::ControlPointMediaServer ( DLNAControlPointMgr & mgr )

inline

Construct helper with reference to control point manager.

Parameters

mgr	Reference to DLNAControlPointMgr used to send actions and manage discovery/subscriptions

Member Function Documentation

◆ begin()

bool tiny_dlna::ControlPointMediaServer::begin	(	DLNAHttpRequest &	http,
		IUDPService &	udp,
		uint32_t	minWaitMs = `3000`,
		uint32_t	maxWaitMs = `60000`
	)

inline

Begin discovery and processing (forwards to underlying control point)

Parameters

http	Http server wrapper used for subscription callbacks
udp	UDP service used for SSDP discovery
minWaitMs	Minimum time in milliseconds to wait before returning
maxWaitMs	Maximum time in milliseconds to wait for discovery

Returns: true on success, false on error

◆ browse()

bool tiny_dlna::ControlPointMediaServer::browse	(	int	startingIndex,
		int	requestedCount,
		ItemCallback	itemCallback,
		int &	numberReturned,
		int &	totalMatches,
		int &	updateID,
		const char *	browseFlag = `nullptr`
	)

inline

Browse the given object_id and invoke callback for each returned item.

Parameters

startingIndex	Starting index for the browse request
requestedCount	Number of items requested
itemCallback	Callback invoked per MediaItem result (may be nullptr)
numberReturned	Output: number of items returned by server
totalMatches	Output: total matches available on server
updateID	Output: server UpdateID
browseFlag	Optional BrowseFlag (defaults to BrowseDirectChildren)

Returns: true on success, false on error

Note: The raw DIDL-Lite XML result is available via getLastReply() -> "Result"

◆ createBrowseAction()

ActionRequest & tiny_dlna::ControlPointMediaServer::createBrowseAction	(	DLNAServiceInfo &	svc,
		const char *	browseFlag,
		int	startingIndex,
		int	requestedCount
	)

inlineprotected

Build a Browse ActionRequest.

◆ findArgument()

const char * tiny_dlna::ControlPointMediaServer::findArgument	(	ActionReply &	r,
		const char *	name
	)

inlineprotected

◆ getDeviceCount()

int tiny_dlna::ControlPointMediaServer::getDeviceCount ( )

inline

Return number of discovered devices known to the control point.

Returns: number of devices matching the optional device type filter

◆ getLastReply()

const ActionReply & tiny_dlna::ControlPointMediaServer::getLastReply ( ) const

inline

Return the ActionReply from the last synchronous request.

Returns: reference to the last ActionReply

◆ getObjectID()

const char * tiny_dlna::ControlPointMediaServer::getObjectID ( ) const

inline

Return the current object id used for browse.

Returns: C-string object id

◆ getProtocolInfo()

const char * tiny_dlna::ControlPointMediaServer::getProtocolInfo ( )

inline

Query ConnectionManager:GetProtocolInfo.

Returns: pointer to protocol info string (Source), or nullptr on error

◆ getSearchCapabilities()

const char * tiny_dlna::ControlPointMediaServer::getSearchCapabilities ( )

inline

Get the ContentDirectory SearchCapabilities string.

Returns: pointer to capability string owned by reply, or nullptr on error

◆ getSortCapabilities()

const char * tiny_dlna::ControlPointMediaServer::getSortCapabilities ( )

inline

Get the ContentDirectory SortCapabilities string.

Returns: pointer to sort capabilities, or nullptr on error

◆ getSystemUpdateID()

int tiny_dlna::ControlPointMediaServer::getSystemUpdateID ( )

inline

Get current SystemUpdateID for the ContentDirectory.

Returns: numeric SystemUpdateID, or -1 on error

◆ parseNumericFields()

void tiny_dlna::ControlPointMediaServer::parseNumericFields	(	ActionReply &	reply,
		int &	numberReturned,
		int &	totalMatches,
		int &	updateID
	)

inlineprotected

Parse numeric result fields from an ActionReply.

◆ processNotification()

static void tiny_dlna::ControlPointMediaServer::processNotification	(	void *	reference,
		const char *	sid,
		const char *	varName,
		const char *	newValue
	)

inlinestaticprotected

Notification callback: just log for now.

◆ processResult()

void tiny_dlna::ControlPointMediaServer::processResult	(	const char *	resultXml,
		ItemCallback	itemCallback
	)

inlineprotected

Parse DIDL-Lite Result and invoke callback for each item.

◆ selectService()

DLNAServiceInfo & tiny_dlna::ControlPointMediaServer::selectService ( const char * id )

inlineprotected

Select service by id.

◆ setDeviceIndex()

void tiny_dlna::ControlPointMediaServer::setDeviceIndex ( int idx )

inline

Select a device by index (0-based) for subsequent actions.

Parameters

idx	Device index

◆ setDeviceTypeFilter()

void tiny_dlna::ControlPointMediaServer::setDeviceTypeFilter ( const char * filter )

inline

Restrict this helper to devices of the given device type.

Parameters

filter Device type string (e.g. "urn:schemas-upnp-org:device:MediaServer:1") Pass nullptr to restore the default filter

◆ setObjectID()

void tiny_dlna::ControlPointMediaServer::setObjectID ( const char * id )

inline

Set the object id used for browse operations (default: "0")

Parameters

id	C-string object id

◆ setReference()

void tiny_dlna::ControlPointMediaServer::setReference ( void * ref )

inline

Attach an opaque reference pointer passed to callbacks.

Parameters

ref	Opaque user pointer

◆ subscribeNotifications()

bool tiny_dlna::ControlPointMediaServer::subscribeNotifications	(	int	timeoutSeconds = `60`,
		NotificationCallback	cb = `nullptr`
	)

inline

Subscribe to event notifications for the selected server/device.

Parameters

timeoutSeconds	Subscription timeout in seconds (default: 60)
cb	Optional notification callback; if nullptr the default `processNotification` will be used

Returns: true on successful SUBSCRIBE, false otherwise

Member Data Documentation

◆ device_index

int tiny_dlna::ControlPointMediaServer::device_index = 0

protected

◆ device_type_filter

const char* tiny_dlna::ControlPointMediaServer::device_type_filter = device_type_filter_default

protected

◆ device_type_filter_default

const char* tiny_dlna::ControlPointMediaServer::device_type_filter_default

protected

Initial value:

=

"urn:schemas-upnp-org:device:MediaServer:1"

◆ last_reply

ActionReply tiny_dlna::ControlPointMediaServer::last_reply

protected

◆ mgr

DLNAControlPointMgr& tiny_dlna::ControlPointMediaServer::mgr

protected

◆ object_id

const char* tiny_dlna::ControlPointMediaServer::object_id = "0"

protected

◆ reference

void* tiny_dlna::ControlPointMediaServer::reference = nullptr

protected

◆ strings

StringRegistry tiny_dlna::ControlPointMediaServer::strings

protected

The documentation for this class was generated from the following file:

src/dlna/clients/ControlPointMediaServer.h
