Helper class to control a MediaRenderer device from a control point. More...

#include <ControlPointMediaRenderer.h>

Collaboration diagram for tiny_dlna::ControlPointMediaRenderer:

[legend]

Public Types
typedef void(*	NotificationCallback) (void reference, const char sid, const char varName, const char newValue)

Public Member Functions
	ControlPointMediaRenderer (DLNAControlPointMgr &mgr)
	Construct the helper with a reference to the control point mgr.

void	setDeviceTypeFilter (const char *filter)
	Restrict this helper to devices of the given device type.

bool	begin (DLNAHttpRequest &http, IUDPService &udp, uint32_t minWaitMs=3000, uint32_t maxWaitMs=60000)
	Begin discovery and processing.

int	getDeviceCount ()
	Return the number of discovered devices matching the renderer filter.

void	setDeviceIndex (int idx)
	Select the active renderer by index (0-based)

bool	subscribeNotifications (int timeoutSeconds=60, NotificationCallback cb=nullptr)
	Subscribe to event notifications for the selected renderer.

void	setInstanceID (const char *id)
	Set the InstanceID used for AVTransport and RenderingControl actions.

bool	setMediaURI (const char *uri)
	Set the media URI on the renderer.

bool	play ()
	Start playback on the renderer.

bool	play (const char *uri)
	Set the media URI and start playback.

bool	pause ()
	Pause playback.

bool	stop ()
	Stop playback.

bool	setVolume (int volumePercent)
	Set renderer volume.

bool	setMute (bool mute)
	Set mute state on the renderer.

int	getVolume ()
	Query the current volume from the renderer.

int	getMute ()
	Query mute state.

unsigned long	getPositionMs ()
	Query current playback position (RelTime)

const char *	getTransportState ()
	Query transport state (e.g. STOPPED, PLAYING, PAUSED_PLAYBACK)

const char *	getCurrentURI ()
	Get the current media URI from the renderer.

int	getNrTracks ()
	Get number of tracks in the current media.

unsigned long	getMediaDurationMs ()
	Get total media duration in milliseconds (from MediaDuration)

int	getTrackIndex ()
	Get current track index (from GetPositionInfo)

unsigned long	getTrackDurationMs ()
	Get current track duration in milliseconds (from TrackDuration)

const ActionReply &	getLastReply () const
	Return last ActionReply (from the most recent synchronous call)

bool	isActive ()
	Query if the helper considers the renderer to be actively playing.

void	setReference (void *ref)
	Attach an opaque reference object that will be passed to callbacks.

void	onActiveChanged (std::function< void(bool, void *)> cb)
	Register a callback invoked when the active (playing) state changes.

Protected Member Functions
void	setActiveState (bool s)

const char *	findArgument (ActionReply &r, const char *name)

DLNAServiceInfo &	selectService (const char *id)

Static Protected Member Functions
static void	processNotification (void reference, const char sid, const char varName, const char newValue)
	Notification callback.

static unsigned long	parseTimeToMs (const char *t)

Protected Attributes
DLNAControlPointMgr &	mgr

bool	is_active = false

std::function< void(bool, void *)>	activeChangedCallback = nullptr

int	device_index = 0

const char *	instance_id = "0"

const char *	device_type_filter_default

const char *	device_type_filter = device_type_filter_default

ActionReply	last_reply

void *	reference = nullptr

Detailed Description

Helper class to control a MediaRenderer device from a control point.

This lightweight helper uses the DLNAControlPointMgr action API to send common AVTransport and RenderingControl actions to the first MediaRenderer service discovered. It is intentionally minimal and returns boolean success/failure for each operation.

Member Typedef Documentation

◆ NotificationCallback

typedef void(* tiny_dlna::ControlPointMediaRenderer::NotificationCallback) (void *reference, const char *sid, const char *varName, const char *newValue)

Constructor & Destructor Documentation

◆ ControlPointMediaRenderer()

tiny_dlna::ControlPointMediaRenderer::ControlPointMediaRenderer ( DLNAControlPointMgr & mgr )

inline

Construct the helper with a reference to the control point mgr.

Parameters

mgr	Reference to the underlying DLNAControlPointMgr used to send actions and manage discovery/subscriptions

Member Function Documentation

◆ begin()

bool tiny_dlna::ControlPointMediaRenderer::begin	(	DLNAHttpRequest &	http,
		IUDPService &	udp,
		uint32_t	minWaitMs = `3000`,
		uint32_t	maxWaitMs = `60000`
	)

inline

Begin discovery and processing.

Parameters

http	Http server wrapper used for subscription callbacks
udp	UDP service used for SSDP discovery
minWaitMs	Minimum time in milliseconds to wait before returning
maxWaitMs	Maximum time in milliseconds to wait for discovery

Returns: true on success, false on error

◆ findArgument()

const char * tiny_dlna::ControlPointMediaRenderer::findArgument	(	ActionReply &	r,
		const char *	name
	)

inlineprotected

◆ getCurrentURI()

const char * tiny_dlna::ControlPointMediaRenderer::getCurrentURI ( )

inline

Get the current media URI from the renderer.

Returns: pointer to URI string (owned by reply registry) or nullptr

◆ getDeviceCount()

int tiny_dlna::ControlPointMediaRenderer::getDeviceCount ( )

inline

Return the number of discovered devices matching the renderer filter.

Returns: number of matching devices

◆ getLastReply()

const ActionReply & tiny_dlna::ControlPointMediaRenderer::getLastReply ( ) const

inline

Return last ActionReply (from the most recent synchronous call)

Returns: reference to the last ActionReply

◆ getMediaDurationMs()

unsigned long tiny_dlna::ControlPointMediaRenderer::getMediaDurationMs ( )

inline

Get total media duration in milliseconds (from MediaDuration)

Returns: milliseconds or 0 on error/unknown

◆ getMute()

int tiny_dlna::ControlPointMediaRenderer::getMute ( )

inline

Query mute state.

Returns: 0 = unmuted, 1 = muted, -1 = error/unknown

◆ getNrTracks()

int tiny_dlna::ControlPointMediaRenderer::getNrTracks ( )

inline

Get number of tracks in the current media.

Returns: number of tracks or -1 on error

◆ getPositionMs()

unsigned long tiny_dlna::ControlPointMediaRenderer::getPositionMs ( )

inline

Query current playback position (RelTime)

Returns: position in milliseconds, or 0 if unknown/error

◆ getTrackDurationMs()

unsigned long tiny_dlna::ControlPointMediaRenderer::getTrackDurationMs ( )

inline

Get current track duration in milliseconds (from TrackDuration)

Returns: milliseconds or 0 on error

◆ getTrackIndex()

int tiny_dlna::ControlPointMediaRenderer::getTrackIndex ( )

inline

Get current track index (from GetPositionInfo)

Returns: track index (numeric) or -1 on error

◆ getTransportState()

const char * tiny_dlna::ControlPointMediaRenderer::getTransportState ( )

inline

Query transport state (e.g. STOPPED, PLAYING, PAUSED_PLAYBACK)

Returns: pointer to a string owned by the helper's registry, or nullptr on error

◆ getVolume()

int tiny_dlna::ControlPointMediaRenderer::getVolume ( )

inline

Query the current volume from the renderer.

Returns: current volume 0..100, or -1 on error

◆ isActive()

bool tiny_dlna::ControlPointMediaRenderer::isActive ( )

inline

Query if the helper considers the renderer to be actively playing.

Returns: true if playing, false otherwise

◆ onActiveChanged()

void tiny_dlna::ControlPointMediaRenderer::onActiveChanged ( std::function< void(bool, void *)> cb )

inline

Register a callback invoked when the active (playing) state changes.

Parameters

cb	Function taking (bool active, void* reference). 'reference' is the pointer set via setReference().

◆ parseTimeToMs()

static unsigned long tiny_dlna::ControlPointMediaRenderer::parseTimeToMs ( const char * t )

inlinestaticprotected

◆ pause()

bool tiny_dlna::ControlPointMediaRenderer::pause ( )

inline

Pause playback.

Returns: true on success, false on error

◆ play() [1/2]

bool tiny_dlna::ControlPointMediaRenderer::play ( )

inline

Start playback on the renderer.

Returns: true on success, false on error

◆ play() [2/2]

bool tiny_dlna::ControlPointMediaRenderer::play ( const char * uri )

inline

Set the media URI and start playback.

Parameters

uri	URI to play

Returns: true on success, false on error

◆ processNotification()

static void tiny_dlna::ControlPointMediaRenderer::processNotification	(	void *	reference,
		const char *	sid,
		const char *	varName,
		const char *	newValue
	)

inlinestaticprotected

Notification callback.

◆ selectService()

DLNAServiceInfo & tiny_dlna::ControlPointMediaRenderer::selectService ( const char * id )

inlineprotected

◆ setActiveState()

void tiny_dlna::ControlPointMediaRenderer::setActiveState ( bool s )

inlineprotected

◆ setDeviceIndex()

void tiny_dlna::ControlPointMediaRenderer::setDeviceIndex ( int idx )

inline

Select the active renderer by index (0-based)

Parameters

idx	Index of the device to select; defaults to 0

◆ setDeviceTypeFilter()

void tiny_dlna::ControlPointMediaRenderer::setDeviceTypeFilter ( const char * filter )

inline

Restrict this helper to devices of the given device type.

Parameters

filter Device type filter, e.g. "urn:schemas-upnp-org:device:MediaRenderer:1". Pass nullptr to use the default MediaRenderer filter.

◆ setInstanceID()

void tiny_dlna::ControlPointMediaRenderer::setInstanceID ( const char * id )

inline

Set the InstanceID used for AVTransport and RenderingControl actions.

Parameters

id	C-string InstanceID (default is "0")

◆ setMediaURI()

bool tiny_dlna::ControlPointMediaRenderer::setMediaURI ( const char * uri )

inline

Set the media URI on the renderer.

Parameters

uri	The media URI to play on the renderer

Returns: true on success, false on error

◆ setMute()

bool tiny_dlna::ControlPointMediaRenderer::setMute ( bool mute )

inline

Set mute state on the renderer.

Parameters

mute	true to mute, false to unmute

Returns: true on success, false on error

◆ setReference()

void tiny_dlna::ControlPointMediaRenderer::setReference ( void * ref )

inline

Attach an opaque reference object that will be passed to callbacks.

Parameters

ref	Opaque pointer provided by the caller

◆ setVolume()

bool tiny_dlna::ControlPointMediaRenderer::setVolume ( int volumePercent )

inline

Set renderer volume.

Parameters

volumePercent Desired volume 0..100

Returns: true on success, false on error

◆ stop()

bool tiny_dlna::ControlPointMediaRenderer::stop ( )

inline

Stop playback.

Returns: true on success, false on error

◆ subscribeNotifications()

bool tiny_dlna::ControlPointMediaRenderer::subscribeNotifications	(	int	timeoutSeconds = `60`,
		NotificationCallback	cb = `nullptr`
	)

inline

Subscribe to event notifications for the selected renderer.

Parameters

timeoutSeconds	Subscription timeout in seconds (suggested default: 60)
cb	Optional callback to invoke for incoming notifications. If nullptr the helper's default `processNotification` will be used.

Returns: true on successful SUBSCRIBE, false otherwise

Member Data Documentation

◆ activeChangedCallback

std::function<void(bool, void*)> tiny_dlna::ControlPointMediaRenderer::activeChangedCallback = nullptr

protected

◆ device_index

int tiny_dlna::ControlPointMediaRenderer::device_index = 0

protected

◆ device_type_filter

const char* tiny_dlna::ControlPointMediaRenderer::device_type_filter = device_type_filter_default

protected

◆ device_type_filter_default

const char* tiny_dlna::ControlPointMediaRenderer::device_type_filter_default

protected

Initial value:

=

"urn:schemas-upnp-org:device:MediaRenderer:1"

◆ instance_id

const char* tiny_dlna::ControlPointMediaRenderer::instance_id = "0"

protected

◆ is_active

bool tiny_dlna::ControlPointMediaRenderer::is_active = false

protected

◆ last_reply

ActionReply tiny_dlna::ControlPointMediaRenderer::last_reply

protected

◆ mgr

DLNAControlPointMgr& tiny_dlna::ControlPointMediaRenderer::mgr

protected

◆ reference

void* tiny_dlna::ControlPointMediaRenderer::reference = nullptr

protected

The documentation for this class was generated from the following file:

src/dlna/clients/ControlPointMediaRenderer.h

Public Types

Public Member Functions

Protected Member Functions

Static Protected Member Functions

Protected Attributes

Detailed Description

Member Typedef Documentation

◆ NotificationCallback

Constructor & Destructor Documentation

◆ ControlPointMediaRenderer()

Member Function Documentation

◆ begin()

◆ findArgument()

◆ getCurrentURI()

◆ getDeviceCount()

◆ getLastReply()

◆ getMediaDurationMs()

◆ getMute()

◆ getNrTracks()

◆ getPositionMs()

◆ getTrackDurationMs()

◆ getTrackIndex()

◆ getTransportState()

◆ getVolume()

◆ isActive()

◆ onActiveChanged()

◆ parseTimeToMs()

◆ pause()

◆ play() [1/2]

◆ play() [2/2]

◆ processNotification()

◆ selectService()

◆ setActiveState()

◆ setDeviceIndex()

◆ setDeviceTypeFilter()

◆ setInstanceID()

◆ setMediaURI()

◆ setMute()

◆ setReference()

◆ setVolume()

◆ stop()

◆ subscribeNotifications()

Member Data Documentation

◆ activeChangedCallback

◆ device_index

◆ device_type_filter

◆ device_type_filter_default

◆ instance_id

◆ is_active

◆ last_reply

◆ mgr

◆ reference
