tiny_dlna::HttpRequest< ClientType > Class Template Reference

Simple API to process get, put, post, del http requests I tried to use Arduino HttpClient, but I did not manage to extract the mime type from streaming get requests. More...

#include <HttpRequest.h>

Inheritance diagram for tiny_dlna::HttpRequest< ClientType >:

Public Member Functions
	HttpRequest ()
	Default constructor.
	HttpRequest (ClientType &client)
	Constructor with specified client.
	~HttpRequest () override
	Destructor.
void	setClient (Client &client) override
	Sets the client to be used for the requests.
void	setHost (const char *host) override
	Sets the host name for the requests.
	operator bool () override
	Checks if the request is valid.
bool	connected () override
	Checks if connected to the server.
int	available () override
	Returns the number of available bytes to read.
void	stop () override
	Stops the connection.
int	post (Url &url, const char *mime, const char *data, int len=-1) override
	Sends a POST request with data.
int	post (Url &url, size_t len, std::function< size_t(Print &, void *)> writer, const char *mime=nullptr, void *ref=nullptr) override
	Sends a POST request with streaming body.
int	notify (Url &url, std::function< size_t(Print &, void *)> writer, const char *mime=nullptr, void *ref=nullptr) override
	Sends a NOTIFY request with streaming body.
int	put (Url &url, const char *mime, const char *data, int len=-1) override
	Sends a PUT request.
int	del (Url &url, const char *mime=nullptr, const char *data=nullptr, int len=-1) override
	Sends a DELETE request.
int	get (Url &url, const char *acceptMime=nullptr, const char *data=nullptr, int len=-1) override
	Sends a GET request.
int	head (Url &url, const char *acceptMime=nullptr, const char *data=nullptr, int len=-1) override
	Sends a HEAD request.
int	subscribe (Url &url) override
	Sends a SUBSCRIBE request.
int	unsubscribe (Url &url, const char *sid) override
	Sends an UNSUBSCRIBE request.
int	read (uint8_t *str, int len) override
	Reads reply data.
int	readln (uint8_t *str, int len, bool incl_nl=true) override
	Reads reply data up to the next new line.
HttpReplyHeader &	reply () override
	Returns the reply header.
HttpRequestHeader &	request () override
	Returns the request header.
void	setAgent (const char *agent) override
	Sets the user agent.
void	setConnection (const char *connection) override
	Sets the connection type.
void	setAcceptsEncoding (const char *enc) override
	Sets the accepted encodings.
Client *	client () override
	Returns the client pointer.
void	setTimeout (int ms) override
	Sets the timeout.

Protected Member Functions
const char *	str (const char *in)
	Returns an empty string if input is null, otherwise returns the input.
virtual int	connect (const char *ip, uint16_t port)
	opens a connection to the indicated host
virtual int	process (TinyMethodID action, Url &url, const char *mime, const char *data, int len=-1)
	sends request and reads the reply_header from the server
virtual int	process (TinyMethodID method, Url &url, size_t len, std::function< size_t(Print &, void *)> writer, const char *mime=nullptr, void *ref=nullptr)

Protected Attributes
ClientType	default_client
Client *	client_ptr = nullptr
Url	url
HttpRequestHeader	request_header
HttpReplyHeader	reply_header
HttpChunkReader	chunk_reader {reply_header}
Str	host_name
const char *	agent = nullptr
const char *	connection = CON_CLOSE
const char *	accept = ACCEPT_ALL
const char *	accept_encoding = nullptr

Detailed Description

template<typename ClientType>
class tiny_dlna::HttpRequest< ClientType >

Simple API to process get, put, post, del http requests I tried to use Arduino HttpClient, but I did not manage to extract the mime type from streaming get requests.

The functionality is based on the Arduino Client class. The template parameter defines the concrete client that will be managed (e.g. WiFiClient); callers must now provide it explicitly.

Template Parameters

ClientType

concrete Arduino client type that implements the Client interface (e.g. WiFiClient, EthernetClient).

Constructor & Destructor Documentation

HttpRequest() [1/2]

template<typename ClientType >

tiny_dlna::HttpRequest< ClientType >::HttpRequest ( )

inline

Default constructor.

HttpRequest() [2/2]

template<typename ClientType >

tiny_dlna::HttpRequest< ClientType >::HttpRequest ( ClientType &  client )

inlineexplicit

Constructor with specified client.

~HttpRequest()

template<typename ClientType >

tiny_dlna::HttpRequest< ClientType >::~HttpRequest ( )

inlineoverride

Destructor.

Member Function Documentation

available()

template<typename ClientType >

int tiny_dlna::HttpRequest< ClientType >::available ( )

inlineoverridevirtual

Returns the number of available bytes to read.

Implements tiny_dlna::IHttpRequest.

client()

template<typename ClientType >

Client * tiny_dlna::HttpRequest< ClientType >::client ( )

inlineoverridevirtual

Returns the client pointer.

Implements tiny_dlna::IHttpRequest.

connect()

template<typename ClientType >

virtual int tiny_dlna::HttpRequest< ClientType >::connect ( const char *  ip, uint16_t  port  )

inlineprotectedvirtual

opens a connection to the indicated host

connected()

template<typename ClientType >

bool tiny_dlna::HttpRequest< ClientType >::connected ( )

inlineoverridevirtual

Checks if connected to the server.

Implements tiny_dlna::IHttpRequest.

del()

template<typename ClientType >

int tiny_dlna::HttpRequest< ClientType >::del ( Url &  url, const char *  mime = nullptr, const char *  data = nullptr, int  len = -1  )

inlineoverridevirtual

Sends a DELETE request.

Implements tiny_dlna::IHttpRequest.

get()

template<typename ClientType >

int tiny_dlna::HttpRequest< ClientType >::get ( Url &  url, const char *  acceptMime = nullptr, const char *  data = nullptr, int  len = -1  )

inlineoverridevirtual

Sends a GET request.

Implements tiny_dlna::IHttpRequest.

head()

template<typename ClientType >

int tiny_dlna::HttpRequest< ClientType >::head ( Url &  url, const char *  acceptMime = nullptr, const char *  data = nullptr, int  len = -1  )

inlineoverridevirtual

Sends a HEAD request.

Implements tiny_dlna::IHttpRequest.

notify()

template<typename ClientType >

int tiny_dlna::HttpRequest< ClientType >::notify ( Url &  url, std::function< size_t(Print &, void *)>  writer, const char *  mime = nullptr, void *  ref = nullptr  )

inlineoverridevirtual

Sends a NOTIFY request with streaming body.

Implements tiny_dlna::IHttpRequest.

operator bool()

template<typename ClientType >

tiny_dlna::HttpRequest< ClientType >::operator bool ( )

inlineoverridevirtual

Checks if the request is valid.

Implements tiny_dlna::IHttpRequest.

post() [1/2]

template<typename ClientType >

int tiny_dlna::HttpRequest< ClientType >::post ( Url &  url, const char *  mime, const char *  data, int  len = -1  )

inlineoverridevirtual

Sends a POST request with data.

Implements tiny_dlna::IHttpRequest.

post() [2/2]

template<typename ClientType >

int tiny_dlna::HttpRequest< ClientType >::post ( Url &  url, size_t  len, std::function< size_t(Print &, void *)>  writer, const char *  mime = nullptr, void *  ref = nullptr  )

inlineoverridevirtual

Sends a POST request with streaming body.

Implements tiny_dlna::IHttpRequest.

process() [1/2]

template<typename ClientType >

virtual int tiny_dlna::HttpRequest< ClientType >::process ( TinyMethodID  action, Url &  url, const char *  mime, const char *  data, int  len = -1  )

inlineprotectedvirtual

sends request and reads the reply_header from the server

process() [2/2]

template<typename ClientType >

virtual int tiny_dlna::HttpRequest< ClientType >::process ( TinyMethodID  method, Url &  url, size_t  len, std::function< size_t(Print &, void *)>  writer, const char *  mime = nullptr, void *  ref = nullptr  )

inlineprotectedvirtual

Shared implementation for streaming requests. Both POST and NOTIFY (and potentially others) can use this to avoid code duplication.

put()

template<typename ClientType >

int tiny_dlna::HttpRequest< ClientType >::put ( Url &  url, const char *  mime, const char *  data, int  len = -1  )

inlineoverridevirtual

Sends a PUT request.

Implements tiny_dlna::IHttpRequest.

read()

template<typename ClientType >

int tiny_dlna::HttpRequest< ClientType >::read ( uint8_t *  str, int  len  )

inlineoverridevirtual

Reads reply data.

Implements tiny_dlna::IHttpRequest.

readln()

template<typename ClientType >

int tiny_dlna::HttpRequest< ClientType >::readln ( uint8_t *  str, int  len, bool  incl_nl = true  )

inlineoverridevirtual

Reads reply data up to the next new line.

Implements tiny_dlna::IHttpRequest.

reply()

template<typename ClientType >

HttpReplyHeader & tiny_dlna::HttpRequest< ClientType >::reply ( )

inlineoverridevirtual

Returns the reply header.

Implements tiny_dlna::IHttpRequest.

request()

template<typename ClientType >

HttpRequestHeader & tiny_dlna::HttpRequest< ClientType >::request ( )

inlineoverridevirtual

Returns the request header.

Implements tiny_dlna::IHttpRequest.

setAcceptsEncoding()

template<typename ClientType >

void tiny_dlna::HttpRequest< ClientType >::setAcceptsEncoding ( const char *  enc )

inlineoverridevirtual

Sets the accepted encodings.

Implements tiny_dlna::IHttpRequest.

setAgent()

template<typename ClientType >

void tiny_dlna::HttpRequest< ClientType >::setAgent ( const char *  agent )

inlineoverridevirtual

Sets the user agent.

Implements tiny_dlna::IHttpRequest.

setClient()

template<typename ClientType >

void tiny_dlna::HttpRequest< ClientType >::setClient ( Client &  client )

inlineoverridevirtual

Sets the client to be used for the requests.

Implements tiny_dlna::IHttpRequest.

setConnection()

template<typename ClientType >

void tiny_dlna::HttpRequest< ClientType >::setConnection ( const char *  connection )

inlineoverridevirtual

Sets the connection type.

Implements tiny_dlna::IHttpRequest.

setHost()

template<typename ClientType >

void tiny_dlna::HttpRequest< ClientType >::setHost ( const char *  host )

inlineoverridevirtual

Sets the host name for the requests.

Implements tiny_dlna::IHttpRequest.

setTimeout()

template<typename ClientType >

void tiny_dlna::HttpRequest< ClientType >::setTimeout ( int  ms )

inlineoverridevirtual

Sets the timeout.

Implements tiny_dlna::IHttpRequest.

stop()

template<typename ClientType >

void tiny_dlna::HttpRequest< ClientType >::stop ( )

inlineoverridevirtual

Stops the connection.

Implements tiny_dlna::IHttpRequest.

str()

template<typename ClientType >

const char * tiny_dlna::HttpRequest< ClientType >::str ( const char *  in )

inlineprotected

Returns an empty string if input is null, otherwise returns the input.

subscribe()

template<typename ClientType >

int tiny_dlna::HttpRequest< ClientType >::subscribe ( Url &  url )

inlineoverridevirtual

Sends a SUBSCRIBE request.

Implements tiny_dlna::IHttpRequest.

unsubscribe()

template<typename ClientType >

int tiny_dlna::HttpRequest< ClientType >::unsubscribe ( Url &  url, const char *  sid  )

inlineoverridevirtual

Sends an UNSUBSCRIBE request.

Implements tiny_dlna::IHttpRequest.

Member Data Documentation

accept

template<typename ClientType >

const char* tiny_dlna::HttpRequest< ClientType >::accept = ACCEPT_ALL

protected

accept_encoding

template<typename ClientType >

const char* tiny_dlna::HttpRequest< ClientType >::accept_encoding = nullptr

protected

agent

template<typename ClientType >

const char* tiny_dlna::HttpRequest< ClientType >::agent = nullptr

protected

chunk_reader

template<typename ClientType >

HttpChunkReader tiny_dlna::HttpRequest< ClientType >::chunk_reader {reply_header}

protected

client_ptr

template<typename ClientType >

Client* tiny_dlna::HttpRequest< ClientType >::client_ptr = nullptr

protected

connection

template<typename ClientType >

const char* tiny_dlna::HttpRequest< ClientType >::connection = CON_CLOSE

protected

default_client

template<typename ClientType >

ClientType tiny_dlna::HttpRequest< ClientType >::default_client

protected

host_name

template<typename ClientType >

Str tiny_dlna::HttpRequest< ClientType >::host_name

protected

reply_header

template<typename ClientType >

HttpReplyHeader tiny_dlna::HttpRequest< ClientType >::reply_header

protected

request_header

template<typename ClientType >

HttpRequestHeader tiny_dlna::HttpRequest< ClientType >::request_header

protected

url

template<typename ClientType >

Url tiny_dlna::HttpRequest< ClientType >::url

protected

---

The documentation for this class was generated from the following file:

• src/http/Server/HttpRequest.h
